• TRD PRO will yield 1" less lift in front and 1" less in rear
• Front Coil Spring Specs
• C59-834 (75mm - 3") 0-110lb Load
• C59-836 (75mm - 3") 110-220lb Load
• C59-838 (100mm - 4") 0-110lb Load
• C59-840 (100mm - 4") 110-220lb Load
• Rear Coil Spring Specs
• C59-817V (Stock Height) Stock Load
• C59-819V (25mm - 1") Stock Load
• C59-821V (50mm - 2") Stock Load / (25mm - 1") 220-440lb Load
• C59-823V (50mm - 2") 220-440lb Load / (25mm - 1") 600-800lb Load
• C59-851V (75mm - 3") Stock Load
• C59-853V (75mm - 3") 220-440lb Load

• 3-way Adjustable shocks provide maximum adjustability to provide the perfect ride quality for you.
• 10 Stage High Speed Compression -For aggressive, high speed off roading through ruts and holes.
• 20 Stage Low Speed Compression - For creepy crawling and cornering
• 15 Stage Rebound - Control your coils, prevent bucking
• 60mm CNC Machined High Flow Billet Aluminium Race Piston
• 2.6" Precision Honed Shock Body
• 3mm Thick Heavy Duty DOM Seamless 66mm O.D. shock Body Precision Honed to +/- 0.04mm
• Upgraded 3 Stage FKM-HNBR Sealing System
• TSUGAMITM CNC machined components for precise tolerances
• ParkerTM Braided High Pressure Hoses
• 5140 HV900 Hard Chrome Plated, Heat treated 18mm Micro-Polished high strength Shock Shaft with a minimum tensile strength exceeding 700MPA
• T6 6061 Height Adjustable Spring Seat
• Carbon-Fibre/PTFE/Disulphide composite wear band for the ultimate in low-friction, low-wear performance
• 60mm Full 6063 aluminum remote reservoir
• Lightweight CNC Machined Low Friction floating piston
• High Quality O.E.M. Grade Natural Rubber Bushings
• Single Piece Lower Leg
• EDP Surface Protection
• Direct Bolt-On Design
• CNC TIG Precision Welded Body End Mounts
• Fully Rebuildable Design
• If doing a 2.5" lift or higher in the front, a diff-drop kit or longer TRD CV-axles are REQUIRED, faliure to complete these requirements could cause OE CV-axle faliure.
• TRD axle shafts: PT362-3432B and PT362-3431B

****Coil seat forMRA59-A446 should be set at 175mm (6.87") from the strut bushing eye to top of coil isolator****
