• Hybrid Tundra Yields 1-1.5" Less Lift in the front
• Front Coil Spring Specs
• C59-834 (50mm - 2") 0-110lb Load
• C59-836 (50mm - 2") 110-220lb Load
• C59-838 (75mm - 3") 0-110lb Load
• C59-840 (75mm - 3") 110-220lb Load
• Rear Coil Spring Specs
• C59-835V (25mm- 1") 0-110lb Load
• C59-837V (25mm- 1") 220-440lb Load
• C59-839V (25mm- 1") 550-770lb Load
• C59-841V (50mm-2") 0-110Lb Load
• C59-843V (50mm-2") 220-440lb Load
• C59-845V (50mm-2") 550-770lb Load
• C97-147VT (50mm-2") 800-1000lb Load
• C97-145VT (50mm-2") 1100-1300lb Load
• Rear Shock Specs
  • MRA59-A887 (Valved for 0-400lb) (Extended Travel)
  • MRA59-A885(Valved for 0-400lb) (Long Travel)
  • MRA59-A687(Valved for 400lb+)(Extended Travel)
  • MRA59-A685(Valved for 400lb+) (Long Travel)

• 3-way Adjustable shocks provide maximum adjustability to provide the perfect ride quality for you.
• 10 Stage High Speed Compression -For aggressive, high speed off roading through ruts and holes.
• 20 Stage Low Speed Compression - For creepy crawling and cornering
• 15 Stage Rebound - Control your coils, prevent bucking
• 60mm CNC Machined High Flow Billet Aluminium Race Piston
• 2.6" Precision Honed Shock Body
• 3mm Thick Heavy Duty DOM Seamless 66mm O.D. shock Body Precision Honed to +/- 0.04mm
• Upgraded 3 Stage FKM-HNBR Sealing System
• TSUGAMITM CNC machined components for precise tolerances
• ParkerTM Braided High Pressure Hoses
• 5140 HV900 Hard Chrome Plated, Heat treated 18mm Micro-Polished high strength Shock Shaft with a minimum tensile strength exceeding 700MPA
• T6 6061 Height Adjustable Spring Seat
• Carbon-Fibre/PTFE/Disulphide composite wear band for the ultimate in low-friction, low-wear performance
• 60mm Full 6063 aluminum remote reservoir
• Lightweight CNC Machined Low Friction floating piston
• High Quality O.E.M. Grade Natural Rubber Bushings
• Single Piece Lower Leg
• EDP Surface Protection
• Direct Bolt-On Design
• CNC TIG Precision Welded Body End Mounts
• Fully Rebuildable Design
• MRA59-A685 / MRA59-A885Long Travel Shocks Require 1.5" bump stop extensions and extended brake lines
• If doing a 2.5" lift or higher in the front, a diff-drop kit or longer TRD CV-axles are REQUIRED, faliure to complete these requirements could cause OE CV-axle faliure.14mm bump stop extensions are also required
• TRD axle shafts: PT362-3432B and PT362-3431B

****Coil seat forMRA59-A446 should be set at 175mm (6.87") from the strut bushing eye to top of coilisolator****

FrontReservoir Instructions

Rear Reservoir Instructions

Strut Assembly Video
